Using hot-rolled steel coil as raw material, after pickling to remove oxide scale, cold rolling is carried out.
Continuous rolling, the finished product is a cold-rolled coil. Due to the cold work hardening caused by continuous cold deformation, the strength, hardness and toughness and plastic index of the hard-rolled coil increase, so the stamping performance will deteriorate, and it can only be used for simple deformed parts. Cold-rolled coils can be used as raw materials for hot-dip galvanizing plants, because hot-dip galvanizing lines are equipped with annealing lines. The weight of rolled hard coil is generally 6~13.5 tons.
|Product||Cold Rolled Steel coil|
|Width||40mm to 400mm|
|Length||as per your requirement|
|Grade||SAE 1043, SAE 1046, 45Mn, S45C, BS108A47|
|Payment terms||T/T, 30% as deposit and 70% before shipment.|
|Delivery time||Within 20-30 days after deposit|
|Package||In bundle/coil, seaworthy package or as requested|
|Application||For short pitch precision roller chains(A series & B series), Walking tractor & rotovator chains, A & B series roller chains for combines, ZGS38 combines chains, rice harvester chains, S,C,A,CA type steel agricultural chains and so on.|
Is galvanized cold rolled steel coil before or after cold rolling? Is it hot dip galvanizing or plating?
Galvanized coil is generally hot galvanized and cold galvanized (electric galvanized)
Cold rolled - galvanized - packaged
Electrogalvanizing is commonly known as cold galvanizing
: is the process of forming uniform, dense and well-combined metal or alloy deposition layer on the surface of the workpiece by using electrolysis of cold rolled substrate.
Electrogalvanizing cost is higher, the surface is good, fingerprint resistance, corrosion resistance, do the surface product fineness is higher
There is also a hot dip galvanizing
Hot rolled - galvanized - packaged
Hot plating is to immerse rust removal into zinc solution melted at about 500℃, so that the surface of steel members is attached with zinc layer, so as to play the purpose of anticorrosion.
The difference between hot rolling and cold rolling?
1. The surface of cold-rolled plate has a certain gloss and feels smooth, similar to the very common steel cup used for drinking water.
2. If the hot rolled plate is not pickled, it is similar to the surface of many ordinary steel plates on the market. The rusted surface is red, and the surface without rust is purple-black (iron oxide).
The performance advantages of cold rolled plate and hot rolled plate are:
1, higher accuracy, cold rolled strip thickness difference is not more than 0.01~0.03mm.
2, thinner size, the thinnest cold rolling can roll 0.001mm steel strip; Hot rolling now reaches a minimum thickness of 0.78mm.
3, the surface quality is superior, cold rolled steel plate can even produce mirror surface; The surface of hot - rolled plate has defects such as iron oxide and pitting.
4, cold rolled sheet can be adjusted according to user requirements of its running performance such as tensile strength and process performance such as stamping performance.
Cold rolling and hot rolling are two different steel rolling technology, as the name implies, cold rolling is to tie steel at room temperature, the hardness of this steel is large. Hot rolling is when steel is tied together at high temperature.
1. Hot rolled
The continuous casting slab or primary rolled slab is used as raw material, heated by stepping heating furnace, descaled by high pressure water and then entered the roughing mill. The roughing material enters the finishing mill after cutting head and tail, and then carried out computer controlled rolling. After the final rolling, it goes through laminar cooling (computer controlled cooling rate) and coiler to become straight hair coil. The head and tail of straight hair coil are often tongue and fishtail, and the accuracy of thickness and width is poor. The side part often has defects such as wave shape, folding edge and tower shape. The coil is heavy and the inner diameter of the steel coil is 760mm. (The general pipe industry likes to use.) After cutting head, cutting tail, cutting edge, straightening, leveling and other finishing line treatment, cutting plate or rewinding, it becomes: hot rolled steel plate, flat hot rolled steel coil, longitudinal cutting tape and other products. Hot rolled finish roll is hot rolled pickling plate roll after pickling removing the oxide scale and oiling. The product has a partial alternative to the trend of cold rolled sheet, moderate price, loved by the majority of users.
2. The cold rolling
The hot rolled steel coil is used as raw material, after removing the oxide scale by pickling, the finished product is rolled hard coil. Due to the cold working hardening caused by continuous cold deformation, the strength and hardness of rolled hard coil increase, and the toughness and plastic index decrease, so the stamping performance will deteriorate, and can only be used for simple deformation parts. Hard roll can be used as raw material for hot-dip galvanizing plant, because hot-dip galvanizing unit is set with quenching line. The weight of rolled hard coil is generally 6~13.5 tons, and the inner diameter of steel coil is 610mm.
Generally, continuous annealing (CAPL unit) or cover furnace annealing should be used to eliminate cold work hardening and rolling stress, so as to achieve the mechanical properties specified in the corresponding standards.
The surface quality, appearance and dimensional accuracy of cold-rolled steel plate are better than that of hot-rolled steel plate, and the thickness of cold-rolled steel plate is about 0.18mm, so it is favored by the majority of users. Cold-rolled steel coil is used as base plate for deep processing of products, and it has become a high value-added product. Such as galvanized, hot dip galvanized, fingerprint galvanized, color coated steel coil and vibration absorption composite steel plate, PVC coated steel plate
Q:What is your terms of payment?
A:We usually accept T/T in advance, L/C for large sum.If you prefer other payments terms, please discuss.
Q:What is the terms of delivery?
A:EXW, FOB, CIF
Q:What is the terms of packing?
A:Generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirements.
Q:What is your delivery time?
A:For products in stock, we can ship it within 7 days after receiving the deposit.For custom order, production time is 15-30
workdays after received the deposit.
Q:Could you produce according to the samples?
A:Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.
Q:How could you guarantee your products?
A:We accept and support the third-party inspection.We also could issue the warranty to customer to guarantee the quality.
Q:How can I get the price of needed product?
A:It's the best way if you can send us the material, size and surface, so we can produce for u to check the quality.If you
still have any confusion, just contact us, we would like to be helpful.
