ALLOY STEEL PIPE description
Shandong Kuaima Steel Pipe Co., Ltd. is a professional manufacturer of alloy steel pipes. Alloy seamless pipe is a kind of seamless steel pipe, its performance is much higher than that of ordinary seamless steel pipe, because this steel pipe contains more Cr, its high temperature resistance, low temperature resistance and corrosion resistance are beyond the reach of other seamless steel pipes. In comparison, alloy tubes are widely used in petroleum, chemical, electric power, boiler and other industries.
email
enquire now
Alloy steel pipes are important materials in the building and construction industry because of their performance characteristics such as ductility, ease of fixing without heat treatment and high durability. They are an alloy of stainless steel, chromium and nickel. Some special types of alloy steel pipes include large diameter welded pipes, electric fusion welded pipes, welded pipes and seamless pipes. They are extremely useful for high-temperature or corrosive applications besides high-pressure .
Alloy steel，When other elements comprising metals and non-metals are added to carbon steel, alloy steel is formed. These alloy steels display various environmental, chemical and physical properties that can vary with the elements used to alloy. Here the proportion of alloying elements can provide different mechanical properties.
Effects of alloying，Alloying elements can alter carbon steel in several ways. Alloying can affect micro-structures, heat-treatment conditions and mechanical properties. Today’s technology with high-speed computers can foresee the properties and micro-structures of steel when it is cold-formed, heat treated, hot-rolled or alloyed. For instance, if properties such as high strength and weldability are required in steel for certain applications, then carbon steel alone will not ..
| Maximum Allowable Pressure (psi) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NPS | Outside Diameter | Schedule | ||||||||||||
| (in) | (in) | 10 | 20 | 30 | STD | 40 | 60 | XS | 80 | 100 | 120 | 140 | 160 | XXS |
| 1/4 | 0.54 | 7985 | 7985 | 10798 | 10798 | |||||||||
| 3/8 | 0.675 | 6606 | 6606 | 9147 | 9147 | |||||||||
| 1/2 | 0.84 | 6358 | 6358 | 8575 | 8575 | 10908 | 17150 | |||||||
| 3/4 | 1.05 | 5273 | 5273 | 7187 | 7187 | 10220 | 14373 | |||||||
| 1 | 1.315 | 4956 | 4956 | 6670 | 6670 | 9316 | 13340 | |||||||
| 1 1/4 | 1.66 | 4133 | 4133 | 5638 | 5638 | 7380 | 11276 | |||||||
| 1 1/2 | 1.9 | 3739 | 3739 | 5158 | 5158 | 7247 | 10316 | |||||||
| 2 | 2.375 | 3177 | 3177 | 4498 | 4498 | 7097 | 8995 | |||||||
| 2 1/2 | 2.875 | 3460 | 3460 | 4704 | 4704 | 6391 | 9408 | |||||||
| 3 | 3.5 | 3024 | 3024 | 4200 | 4200 | 6132 | 8400 | |||||||
| 3 1/2 | 4 | 2769 | 2769 | 3896 | 3896 | |||||||||
| 4 | 4.5 | 2581 | 2581 | 3670 | 3670 | 4769 | 5782 | 7339 | ||||||
| 5 | 5.563 | 2273 | 2273 | 3303 | 3303 | 4404 | 5505 | 6606 | ||||||
| 6 | 6.625 | 2071 | 2071 | 3195 | 3195 | 4157 | 5318 | 6390 | ||||||
| 8 | 8.625 | 1420 | 1574 | 1829 | 1829 | 2307 | 2841 | 2841 | 3375 | 4085 | 4613 | 5147 | 4971 | |
| 10 | 10.75 | 1140 | 1399 | 1664 | 1664 | 2279 | 2279 | 2708 | 3277 | 3847 | 4558 | 5128 | 4558 | |
| 12 | 12.75 | 961 | 1268 | 1441 | 1560 | 2160 | 1922 | 2644 | 3244 | 3843 | 4324 | 5042 | 3843 | |
| 14 | 14 | 875 | 1092 | 1313 | 1313 | 1533 | 2079 | 1750 | 2625 | 3283 | 3829 | 4375 | 4921 | |
| 16 | 16 | 766 | 956 | 1148 | 1148 | 1531 | 2009 | 1531 | 2585 | 3157 | 3733 | 4404 | 4882 | |
| 18 | 18 | 681 | 849 | 1192 | 1021 | 1530 | 2042 | 1361 | 2553 | 3147 | 3743 | 4252 | 4848 | |
| 20 | 20 | 613 | 919 | 1225 | 919 | 1455 | 1989 | 1225 | 2526 | 3138 | 3675 | 4288 | 4824 | |
| 22 | 22 | 557 | 835 | 1114 | 835 | 1949 | 1114 | 2506 | 3063 | 3619 | 4176 | 4733 | ||
| 24 | 24 | 510 | 766 | 1147 | 766 | 1405 | 1978 | 1021 | 2489 | 3126 | 3700 | 4210 | 4786 | |
| 30 | 30 | 510 | 817 | 1021 | 613 | 817 | ||||||||
| 32 | 32 | 478 | 766 | 957 | 574 | 1054 | ||||||||
| 34 | 34 | 450 | 721 | 901 | 540 | 992 | ||||||||
| 36 | 36 | 425 | 681 | 851 | 510 | 1021 | ||||||||
| 42 | 42 | 583 | 729 | 438 | 875 | |||||||||
| Alloy Steel Pipe Types | Out diameter | Wall thickness | Length |
|---|---|---|---|
| NB Sizes (in stock) | 1/8” ~ 8” | SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 | Upto 6 Meters |
| Alloy Steel Seamless Pipe (Custom Sizes) | 5.0mm ~ 203.2mm | As per requirement | Upto 6 Meters |
| Alloy Steel Welded Pipe (in Stock + Custom Sizes) | 5.0mm ~ 1219.2mm | 1.0 ~ 15.0 mm | Upto 6 Meters |
| Size Range | 1/8" - 26" |
| Schedules | 20 SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Standards | ASME, ASTM |
| Type | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
| Form | Round, Square, Rectangular, Hydraulic Etc. |
| End | Plain End, Beveled End, Treaded. |
| Length | Single Random, Double Random & Cut Length, Min 3 Meters, Max18 Meters, or according to customer’s requirement |
| Dimensions | ASTM, ASME and API |
| Size | ½” nominal through 60” OD |
| Wall Thickness | up through 4” thick& heavier upon request |
| Alloy Steel Pipes Specifications & Grades |
|
| Alloy Steel Tubes Specifications & Grades |
|
| Origin | China |
| Specialized in | Large Diameter Alloy Steel Pipe, alloy steel seamless pipe suppliers, alloy steel erw tubes, welded alloy steel pipes |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce alloy steel pipe, hot/cold rolled steel, galvanized steel, galvanized steel, prepainted steel and stainless steel coils, strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
| alloy seamless steel pipe | alloy steel and pipe |
| alloy steel pipe a214 | alloy steel pipe china |
| alloy steel pipe a333 t91 | alloy steel pipe company |
| alloy steel pipe fittings | cheap a335 p5 alloy steel pipe |
| alloy steel pipe for heat exchangers | alloy steel pipe suppliers |
| alloy steel pipe manufacturers | alloy steel seamless pipe |
| alloy steel pipes suppliers | alloy steel seamless pipes |
| cheap alloy steel pipe gb5310 | astm a335 p11 alloy steel pipe |
We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.
thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength
We are a world-renowned Alloy steel pipe exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries.
