Galvanized iron wire is made with mild steel, hard-drawn, and then galvanized. It is rust-resistant, and very versatile in applications. Galvanized iron wire can be supplied in the form of coil wire, spool wire or further processed into straightened cut wire or U type wire.Applications of Galvanized Iron Wire: Galvanized iron wire is mainly used in construction as binding wire, express way fencing as fencing wire, binding of flowers as wire ties in the garden and yard, and wire mesh making as weaving wires.
Three Stages of Galvanized Steel Wire Production:
1.Pickling and decontamination of the entire roll of strip steel to achieve a bright and clean surface.
2.After pickling, it is cleaned in a tank of ammonium chloride or zinc chloride aqueous solution or mixed aqueous solution of ammonium chloride and zinc chloride, and then sent to a hot dip plating tank for galvanizing.
3.The strip is galvanized and put into storage. The galvanized layer can be customized according to customer needs, generally not less than 500g/square meter, and any sample shall not be less than 480g/square meter.
Diameter and Tolerance (mm) | Tensile strength (Mpa) | Elongation | Torsion | Zinc Coating Weight (g/㎡) | ||
% | Times | Hot dipped heavy zinc coated | Hot dipped Normal zinc coated | Electro Galvanized zinc coated | ||
0.2±0.02 | 350-550 | ≥15 | ≥45 | ≥25 | ≥15 | ≥8 |
0.3±0.025 | 350-550 | ≥15 | ≥45 | ≥30 | ≥15 | ≥10 |
0.5±0.025 | 350-550 | ≥12 | ≥45 | ≥40 | ≥20 | ≥10 |
0.7±0.03 | 350-550 | ≥10 | ≥42 | ≥45 | ≥40 | ≥15 |
0.9±0.03 | 350-550 | ≥10 | ≥33 | ≥155 | ≥50 | ≥15 |
1.25±0.04 | 350-550 | ≥10 | ≥24 | ≥180 | ≥50 | ≥15 |
1.6±0.05 | 350-550 | ≥10 | ≥37 | ≥195 | ≥50 | ≥15 |
2.0±0.05 | 350-550 | ≥10 | ≥30 | ≥215 | ≥50 | ≥15 |
2.5±0.06 | 350-550 | ≥10 | ≥24 | ≥245 | ≥50 | ≥15 |
3.15±0.07 | 350-550 | ≥10 | ≥19 | ≥260 | ≥50 | ≥15 |
4.0±0.07 | 350-550 | ≥10 | ≥15 | ≥275 | ≥70 | ≥15 |
5.0±0.08 | 350-550 | ≥10 | ≥15 | ≥280 | ≥80 | ≥15 |
6.0±0.08 | 350-550 | ≥10 | ≥15 | ≥290 | ≥80 | ≥15 |
Wire Gauge Size | SWG(mm) | BWG(mm) | BG(mm) |
6 | 4.87 | 5.15 | 5.032 |
7 | 4.47 | 4.57 | 4.481 |
8 | 4.06 | 4.19 | 3.988 |
9 | 3.66 | 3.76 | 3.551 |
10 | 3.25 | 3.40 | 3.175 |
11 | 2.95 | 3.05 | 2.827 |
12 | 2.64 | 2.77 | 2.517 |
13 | 2.34 | 2.41 | 2.24 |
14 | 2.03 | 2.11 | 1.994 |
15 | 1.83 | 1.83 | 1.775 |
16 | 1.63 | 1.65 | 1.588 |
17 | 1.42 | 1.47 | 1.412 |
18 | 1.22 | 1.25 | 1.257 |
19 | 1.02 | 1.07 | 1.118 |
20 | 0.91 | 0.89 | 0.996 |
21 | 0.81 | 0.813 | 0.887 |
22 | 0.71 | 0.711 | 0.749 |
23 | 0.61 | 0.635 | 0.707 |
24 | 0.56 | 0.559 | 0.629 |
25 | 0.51 | 0.508 | 0.56 |
26 | 0.46 | 0.457 | 0.498 |
Product Name | Galvanized Steel Wire |
Steel Grade | Q195-Q235,Q235,SAE 1008-1018 45#,50#,55#,60#,70# |
Type | Drawn Wire |
Coil weight | 1.8~2.1mts |
Standard | DIN GB ISO JIS BA ANSI |
Payment terms | L/C T/T (30%DEPOSIT) |
Place of origin | Shandong China |
Wire Gauge | SWG(mm) | BWG(mm) | Metric(mm) |
8 | 4.05 | 4.19 | 4.00 |
9 | 3.66 | 3.76 | 4.00 |
10 | 3.25 | 3.40 | 3.50 |
11 | 2.95 | 3.05 | 3.00 |
12 | 2.64 | 2.77 | 2.80 |
13 | 2.34 | 2.41 | 2.50 |
14 | 2.03 | 2.11 | 2.50 |
15 | 1.83 | 1.83 | 1.80 |
16 | 1.63 | 1.65 | 1.65 |
17 | 1.42 | 1.47 | 1.40 |
18 | 1.22 | 1.25 | 1.20 |
19 | 1.02 | 1.07 | 1.00 |
20 | 0.91 | 0.84 | 0.90 |
21 | 0.81 | 0.81 | 0.80 |
22 | 0.71 | 0.71 | 0.70 |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce hot/cold rolled steel, galvanized steel, galvanized steel, prepainted steel and stainless steel coils, Galvanized steel wire,strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
different gauge of galvanized steel wire for snares | china galvanized steel wire mesh deck railing |
different guage of galvanized steel wire for snares | china steel wire electro galvanizing machine |
does galvanized steel wire stretch | cost of galvanized steel wire |
durabrite hot dipped heavy duty galvanized steel wire rope thimble | cut galvanized steel pipe with wire |
earth wire is made of galvanized steel | cut galvanized steel wire |
easypetfence 100' welded wire-14 ga. galvanized steel core | cutter for 14 gauge galvanized steel wire |
electrical resistance of galvanized steel wire | cutting 14 gauge galvanized steel wire coils |
electro galvanized steel wire pricelist | cutting chainmail rings 14 gauge galvanized steel wire |
We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.
thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength
We are a world-renowned Galvanized steel wire exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries
Speak to a Steel Expert
