4mm High tensile Galvanized steel wire Dealer
Galvanized steel wire adopts mixed plating and drawing process to produce ultra-high-strength galvanized steel wire.
The process flow is as follows: lead quenching—one drawing—pre-galvanizing—second drawing—final galvanizing—three drawing (dry drawing)—water tank drawing a finished steel wire. The above process can produce ultra-high-strength galvanized steel wire with a carbon content of 0.93-0.97%, a diameter of 0.26 mm, and a strength of 3921 N/mm2. During drawing, the zinc layer protects and lubricates the surface of the steel wire, and no wire breakage occurs during drawing.
Galvanized steel wire is mainly used for planting greenhouses, farms, cotton packaging, spring and wire rope manufacturing. It is suitable for cable-stayed bridge, sewage tank and other engineering structures with bad environmental conditions.
1. Durability: In the suburban environment, the standard anti-rust thickness of hot-dip galvanizing can be maintained for more than 30 years without repair; In urban or offshore areas, the standard galvanized antirust coating can be maintained for 15 years without repair.
2. Good reliability: the zinc coating is combined with steel metallurgy to become a part of the steel surface, and the coating is reliable.
3. Strong coating toughness: the galvanized layer of galvanized wire forms special metallographic structure, which can withstand mechanical damage during transportation and use.
4. Comprehensive protection: every part of the galvanized wire can be galvanized, and even the concave and sharp corners can be fully protected.
5. Save time and effort: the galvanizing process is faster than other painting methods, which can avoid the time required for painting at the construction site after installation.
Wire gauge size | SWG | mm | BWG | mm |
Inch | Inch | |||
8 | 0.160 | 4.06 | 1.165 | 4.19 |
9 | 0.144 | 3.66 | 0.148 | 3.76 |
10 | 0.128 | 3.25 | 0.134 | 3.40 |
11 | 0.116 | 2.95 | 0.120 | 3.05 |
12 | 0.104 | 2.64 | 0.109 | 2.77 |
13 | 0.092 | 2.34 | 0.095 | 2.41 |
14 | 0.080 | 2.03 | 0.083 | 2.11 |
15 | 0.072 | 1.83 | 0.072 | 1.83 |
16 | 0.064 | 1.63 | 0.065 | 1.65 |
17 | 0.056 | 1.42 | 0.058 | 1.47 |
18 | 0.048 | 1.22 | 0.049 | 1.25 |
19 | 0.040 | 1.02 | 0.042 | 1.07 |
20 | 0.036 | 0.91 | 0.035 | 0.89 |
21 | 0.032 | 0.81 | 0.032 | 0.813 |
22 | 0.028 | 0.71 | 0.028 | 0.711 |
23 | 0.024 | 0.61 | 0.025 | 0.64 |
24 | 0.022 | 0.61 | 0.022 | 0.56 |
25 | 0.020 | 0.51 | 0.020 | 0.51 |
26 | 0.018 | 0.46 | 0.018 | 0.46 |
27 | 0.016 | 0.42 | 0.016 | 0.41 |
28 | 0.015 | 0.038 | 0.014 | 0.36 |
29 | 0.014 | 0.35 | 0.013 | 0.33 |
30 | 0.0124 | 0.32 | 0.012 | 0.31 |
31 | 0.012 | 0.30 | 0.010 | 0.25 |
32 | 0.011 | 0.27 | 0.009 | 0.23 |
33 | 0.010 | 0.25 | 0.008 | 0.20 |
34 | 0.009 | 0.23 | 0.007 | 0.018 |
35 | 0.008 | 0.21 | 0.005 | 0.13 |
36 | 0.0076 | 0.19 | 0.004 | 0.10 |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce hot/cold rolled steel, galvanized steel, galvanized steel, prepainted steel and stainless steel coils, Galvanized steel wire,strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
16 gauge galvanized steel wire | galvanized carbon steel wire |
17 gauge galvanized steel wire | galvanized steel welded wire |
18 gauge galvanized steel wire | galvanized steel barbed wire |
19 gauge galvanized steel wire | galvanized stainless steel wire |
20 gauge galvanized steel wire | galvanized spring steel wire |
22 gauge galvanized steel wire | galvanized steel wire 20 gauge |
24 gauge galvanized steel wire | galvanized steel wire 9 gauge |
28 gauge galvanized steel wire | galvanized steel wire factory |
We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.
thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength
We are a world-renowned Galvanized steel wire exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries
