ASTM ss400 Gi steel angle perforated with holes
ASTM ss400 Gi Angle steel is a carbon structural steel for construction, is a simple section of section steel, ASTM ss400 Gi Angle steel Widely used in various building structures and engineering structures, such as house beams, bridges, transmission towers，power piping, busbar bracket installation, and warehouse shelves, etc.
email
enquire now
1、Steel angles play a vital role in the construction industry to give structural support to the buildings. These steels are manufactured from hot-rolled carbon steel or high strength low alloy steel. The steel angle bends at an angle to form 90 degrees. This structure helps the building to bear the stress of the load and material.
2、The prime application of steel angle in the construction industry is in the bridge ways.It is because the coating protects the material from corrosion and increases its resistance of the material.
3、The appliances in the houses and heavy equipment like a bulldozer, road roller, and much more use steel. The home appliances are reinforced with steel angles to protect the edges from damages.
CHEMICAL COMPOSITION | |
| Element | Percentage |
| C | 0.26 |
| Cu | 0.2 |
| Fe | 99 |
| Mn | 0.75 |
| P | 0.04 max |
| S | 0.05 max |
MECHANICAL INFORMATION | ||
| Imperial | Metric | |
| Density | 0.282 lb/in3 | 7.8 g/cc |
| Ultimate Tensile Strength | 58,000psi | 400 MPa |
| Yield Tensile Strength | 47,700psi | 315 MPa |
| Shear Strength | 43,500psi | 300 MPa |
| Melting Point | 2,590 - 2,670°F | 1,420 - 1,460°C |
| Hardness Brinell | 140 |
| Production Method | Hot Rolled |
AVAILABLE SIZES | |||
| Size | Thickness | Length | Weight (lbs/ft) |
| 1" x 1" x 1/8" | 1/8" | 240.00" | 0.856 |
| 1" x 1" x 3/16" | 3/16" | 240.00" | 1.241 |
| 1" x 1" x 1/4" | 1/4" | 240.00" | 1.594 |
| 1-1/4" x 1-1/4" x 1/8" | 1/8" | 240.00" | 1.080 |
| 1-1/4" x 1-1/4" x 3/16" | 3/16" | 240.00" | 1.695 |
| 1-1/2" x 1-1/2" x 1/8" | 1/8" | 240.00" | 1.316 |
| 1-1/2" x 1-1/2" x 3/16" | 3/16" | 240.00" | 1.926 |
| 1-1/2" x 1-1/2" x 1/4" | 1/4" | 240.00" | 2.527 |
| 2" x 2" x 1/8" | 1/8" | 240.00" | 1.766 |
| 2" x 2" x 3/16" | 3/16" | 240.00" | 2.625 |
| 2" x 2" x 1/4" | 1/4" | 240.00" | 3.413 |
| 2-1/2" x 2-1/2" x 3/16" | 3/16" | 240.00" | 3.285 |
| 2-1/2" x 2-1/2" x 1/4" | 1/4" | 240.00" | 4.387 |
| 3" x 3" x 3/16" | 3/16" | 240.00" | 3.970 |
| 3" x 3" x 1/4" | 1/4" | 240.00" | 5.243 |
| 3" x 3" x 3/8" | 3/8" | 240.00" | 7.704 |
| 4" x 4" x 1/4" | 1/4" | 240.00" | 7.062 |
| 4" x 4" x 3/8" | 3/8" | 240.00" | 10.486 |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce hot/cold rolled steel, galvanized steel, galvanized steel, prepainted steel and stainless steel coils,galvanized angle steel,strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
| ASTM ss400 Gi steel angle perforated with holes standard sizes | 1 2 inch ASTM ss400 Gi steel angle perforated with holes |
| ASTM ss400 Gi steel angle perforated with holes magnetic catch | ASTM ss400 Gi steel angle perforated with holes steel angle |
| ASTM ss400 Gi steel angle perforated with holes angle corner protectors | 1 2 x1 2 ASTM ss400 Gi steel angle perforated with holes angle |
| can i ASTM ss400 Gi steel angle perforated with holes | 1 inch ASTM ss400 Gi steel angle perforated with holes iron |
| can you cut ASTM ss400 Gi steel angle perforated with holes | 1 stainless ASTM ss400 Gi steel angle perforated with holes |
| contact angle ASTM ss400 Gi steel angle perforated with holes | 1/16 thick ASTM ss400 Gi steel angle perforated with holes angle |
| ASTM ss400 Gi steel angle perforated with holes with angle grinder | 16 gauge angled finish ASTM ss400 Gi steel angle perforated with holesl |
| ASTM ss400 Gi steel angle perforated with holes with angle grinder | 16 gauge stainless ASTM ss400 Gi steel angle perforated with holes |
We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.
thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength
We are a world-renowned Galvanized angle steel exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries.
