stainless steel plate
buy Stainless Steel plate
430 Stainless Steel plate

Product Desceription of Stainless Steel Plate

Stainless steel sheet, also known as plate and stainless steel sheet, is a modern, versatile product used in a variety of construction and manufacturing projects. Benefits include corrosion resistance, fire and heat resistance, as well as a good strength-to-weight ratio and better appearance compared to other metals. Stainless steel sheet is a modern multi-purpose product used in a variety of construction and fabrication projects.

  • facebook icon
  • instagram icon
  • whatsapp icon
  • youtube icon
  • twitter icon
  • tiktok icon

Industrial use of stainless steel plate

  • Excellent Physical Properties,Kuaima stainless steel possesses higher thermal conductivity, smaller thermal expansion coefficient, less material weight for same size than other suppliers.
  • Heat Resistance,304 has good resistance to oxidation in intermittent service up to 870°C and in continuous service to 925°C. However, continuous use at 425-860°C is not recommended if corrosion resistance in water is required. In this instance 304L is recommended due to its resistance to carbide precipitation.Where high strength in required at temperatures above 500°C and up to 800°C, grade 304H is recommended. This material will retain aqueous corrosion resistance.

  • Fabrication,Fabrication of all stainless steels should be done only with tools dedicated to stainless steel materials. Tooling and work surfaces must be thoroughly cleaned before use. These precautions are necessary to avoid cross contamination of stainless steel by easily corroded metals that may discolor the surface of the fabricated products.

  • Cold Working,304 stainless steel readily work hardens. Fabrication methods involving cold working may require an intermediate annealing stage to alleviate work hardening and avoid tearing or cracking. At the completion of fabrication a full annealing operation should be employed to reduce internal stresses and optimize corrosion resistance.

  • Hot Working,Fabrication methods, like forging, that involve hot working should ovvur after uniform heating to 1149-1260°C. The fabricated components should then be rapidly cooled to ensure maximum corrosion resistance.
  • Heat Treatment,304 stainless steel cannot be hardened by heat treatment. Solution treatment or annealing can be done by rapid cooling after heating to 1010-1120°C.


  • video play button
  • china 316 stainless steel plate
  • hot rolled stainless steel coil plate
cut-off rule

Chemical and Mechanical Properties of Stainless Steel Plate:

Typical chemical requirements
 304304L316/316L321
Carbon, Max %0.070.030.030.08
Manganese, Max %2222
Phosphorus, Max %0.0450.0450.0450.045
Sulphur, Max %0.030.030.030.03
Silicon Max0.750.750.750.75
Chromium range17.5-19.517.5-19.516-1817-19
Nickel range8.0-10.580.-1210-149-12
Nitrogen Max0.10.10.10.1
Mechanical Properties
Tensile Min75 ksi70 ksi75 ksi75 ksi
Yield Min30 ksi25 ksi25 ksi30 ksi
Elongation Min40%40%40%40%
Hardness Max95 HRB95 HRB95 HRB95 HRB

Product Specification of stainless steel plate

Material

200 300 400 Series stainless steel

Grade

201 202 301 303 304 304L 309 309S 310 310S 316 316L 316Ti 317L 321 2205 2507 409 409l 410 410S 420 420J1 420J2 430 441 444 904L

Standard

AiSi ASTM JIS DIN EN BS

Tech

cold rolled / hot rolled

Thickness

Hot rolled: 3mm-16mm 16-150mm

Normal: 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0
As per customer’s request: 16-150mm

Cold rolled: 0.3-6mm
Normal:0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0
As per customer’s request: 4.0/5.0/6.0

Width&Length

1000mm-6000mm, or as per customer's request
Hot rolled: 1250*3000mm (4.1*10ft) 1500*3000mm (5*10ft)
1250*6000mm (4.1*19.6ft) 1500*6000mm (5*19.6ft)
1800*6000mm (5.9*19.6ft) 2000*6000mm(6.5*19.6ft)
Cold rolled: 1000*2000mm (3.2*6.5ft) 1219*2438mm (4*8ft)
1500*3000mm (5*10ft)
1800 available 2000 available

Place of Origin

Jiangsu China

Processing Service

Bending, Welding, Recoiling, Punching, Cutting

Tolerance

±1%

Surface Treatment

N0.1,2B,BA,6K, 8K, 12k, N0.4, HL, Mirrored,checkered etc

Payment

T/T terms, 30% pre-payment, 70% balance see B/L copy

Delivery Time

5-15 days for ordinary orders (standard orders ≦50 ton); specified orders needs final confirmation as per customer’s request

contact icon call us now! +86-18365977887 Or write to us at Echo@kuaimasteel.com

201 stainless steel plate price production line

  • 201 stainless steel plate factory
  • china 304l stainless steel plate supplier
  • 304 stainless steel plate factory

Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce stainless steel plate,hot/cold rolled steel, galvanized steel, galvanized steel, prepainted steel and stainless steel coils, strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.

hot sale product

201 stainless steel plate factory 304 stainless steel plate 1 2 inch
china 301 stainless steel plate manufacturer 304 stainless steel plate 1 2 inch 25 feet
china 304l stainless steel plate supplier 304 stainless steel plate factories
china 304l stainless steel plate supplier 304 stainless steel plate factory
china 316 stainless steel plate 304 stainless steel plate manufacturer
china 316l stainless steel plate 304 stainless steel plate supplier
china 430 stainless steel plate 304 stainless steel plate factory
china cold rolled stainless steel plate 304 stainless steel plate tube

china 316 stainless steel plate QUALITY INSPECTION

We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.

thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength

  • stainless steel 304  plate prices
  • stainless steel  plate 316
  • wholesale stainless steel  plate
  • 24 gauge stainless steel  plate
cut-off rule

stainless steel plate application industry

  • Machinery manufacturing industry
    Machinery manufacturing industry
  • Oil & Gas Industries
    Oil & Gas Industries
  • Construction industry
    Construction industry
  • Shipbuilding industry
    Shipbuilding industry
  • Chemical industry
    Chemical industry
  • Power Generation
    Power Generation

Our main export countries

We are a world-renowned stainless steel plate exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries
