WEAR-RESISTANT STEEL PLATE
Abrasion resistant steel is harder than carbon steel. Abrasion resistant steel plate is an alloy steel plate and the alloy has formability and weather resistance. Wear-resistant steel plate is usually produced using the muddy fire process, which increases the three-dimensional shape of the steel to form a unique grain.
Some of the applications abrasion resistant steel plate is used in are:Mining industry machinery,Industrial hoppers, funnels and feeders,Platform structures,Heavy wear platforms,Earth moving machinery
Steel Grade | C | Si | Mn | P | S | Cr | Mo | B | N | H | Ceq |
NM360/NM400 | ≤0.20 | ≤0.40 | ≤1.50 | ≤0.012 | ≤0.005 | ≤0.35 | ≤0.30 | ≤0.002 | ≤0.005 | ≤0.00025 | ≤0.53 |
NM450 | ≤0.22 | ≤0.60 | ≤1.50 | ≤0.012 | ≤0.005 | ≤0.80 | ≤0.30 | ≤0.002 | ≤0.005 | ≤0.00025 | ≤0.62 |
NM500 | ≤0.30 | ≤0.60 | ≤1.00 | ≤0.012 | ≤0.002 | ≤1.00 | ≤0.30 | ≤0.002 | ≤0.005 | ≤0.0002 | ≤0.65 |
NM550 | ≤0.35 | ≤0.40 | ≤1.20 | ≤0.010 | ≤0.002 | ≤1.00 | ≤0.30 | ≤0.002 | ≤0.0045 | ≤0.0002 | ≤0.72 |
Steel Grade | Yield Strength /MPa | Tensile Strength /MPa | Elongation A50 /% | Hardess (Brinell) HBW10/3000 | Impact/J (-20℃) |
NM360 | ≥900 | ≥1050 | ≥12 | 320-390 | ≥21 |
NM400 | ≥950 | ≥1200 | ≥12 | 380-430 | ≥21 |
NM450 | ≥1050 | ≥1250 | ≥7 | 420-480 | ≥21 |
NM500 | ≥1100 | ≥1350 | ≥6 | ≥470 | ≥17 |
NM550 | - | - | - | ≥530 | - |
Abrasion Resistant Steel Plate Availabillity
Grade | Thickness | Width | Length |
AR200 / AR 235 | 3/16" – 3/4" | 48" – 120" | 96" – 480" |
AR400F | 3/16" – 4" | 48" – 120" | 96" – 480" |
AR450F | 3/16" – 2 " | 48" – 96 " | 96" – 480" |
AR500 | 3/16" – 2 " | 48" – 96 " | 96" – 480" |
AR600 | 3/16" – 3/4" | 48" – 96 " | 96" – 480" |
Chemical Composition of Abrasion Resistant Steel Plate
Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
AR500 | 0.30 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
AR450 | 0.26 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
AR400 | 0.25 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.70 | 0.50 | 0.005 |
AR300 | 0.18 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.40 | 0.50 | 0.005 |
Mechanical Properties of Abrasion Resistant Steel Plate
Grade | Yield Strength MPa | Tensile Strength MPa | Elongation A | Impact Strength Charpy V 20J | Hardness Range |
AR500 | 1250 | 1450 | 8 | -30C | 450-540 |
AR450 | 1200 | 1450 | 8 | -40C | 420-500 |
AR400 | 1000 | 1250 | 10 | -40C | 360-480 |
AR300 | 900 | 1000 | 11 | -40C | - |
Product Name | abrasion resistant steel plate NM400 NM450 NM500 RAEX450 nm600wear resistant steel plate |
Steel type | Carbon steel, special alloy steel or as requested |
Color | Process Method |
Other processing method | Cutting, bending, punching, or as customer's request |
Size | Thickness from 0.15mm-300mm, width from 50mm-3500mm, length from 1m-12m or according to customer's special request |
Material grade | NM360,NM400,NM450,NM500,NR360,NR400 |
Standard | AISI, ASTM, BS, DIN, GB, JIS |
Surface | mild steel plain finish, hot dip galvanized, color coated, ect. |
Size Tolerance | +/- 1%~3% |
Yield Strength | 250~600 MPa |
Tensile Strength | 350~800 MPa |
Packaging | Bundled with strong steel strips or with waterproof packing materials |
Certificate | API,ISO,SGS,BV,etc |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce Wear-resistant steel plate,hot/cold rolled steel, galvanized steel, galvanized steel, prepainted steel and stainless steel coils, strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
Wear-resistant steel plate suppliers in china | current price of Wear-resistant steel plate |
Wear-resistant steel plate quotes | high Wear-resistant steel plate grades |
Wear-resistant steel plate pricing | wholesale Wear-resistant steel plate factory |
wholesale Wear-resistant steel plate | Wear-resistant steel plate standard |
high quality Wear-resistant steel plate | hardness of Wear-resistant steel plate |
Wear-resistant steel plate price list | hardness of Wear-resistant manufacturers |
Wear-resistant steel plate uses | low price Wear-resistant steel plate |
china Wear-resistant steel plate | Wear-resistant steel plate standard |
We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.
thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength
We are a Wear-resistant steel plate exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries
