Thick wall seamless steel pipe
Chinese manufacturer, complete production line, with fine thick wall seamless pipe processing workshop. High-quality carbon steel pipe, support customization, email quotation. international standard. made in China. Model: stainless steel, carbon steel, aluminum products.
email
enquire now
Thick-walled steel pipes are mainly used in pipeline transportation and can be used to transport some liquids, for example, some electric energy, crude oil, and some surface water transportation, which can all be completed with the help of thick-walled steel pipes. In modern society, thick-walled steel pipes The application industry and scope of the 16Mn thick-walled steel pipe is once again the main use is very common. Thick-walled steel pipes for general main purposes are cold-rolled from ordinary carbon steel, low-alloy tool steel or alloy tool steel, and have a large amount of processing. They are mainly used as pipelines or structural parts for transporting liquids. Thick-walled steel pipes made of this type of steel are widely used. It is used in every field such as metal briquetting machine, high pressure gas cylinder, boiler, organic fertilizer machinery and equipment, petroleum cracking, automobile half-shaft sleeve, diesel engine and so on.
The raw material for rolling seamless tubes is a round tube blank, which is cut by a cutting machine into a billet with a length of about 1 meter, and sent to a furnace for heating through a conveyor belt. The billets are fed into the furnace and heated at about 1200 degrees Celsius. The fuel is hydrogen or acetylene. Furnace temperature control is a critical issue. After the round tube blank is released, it will be perforated by a pressure perforator. Generally, the more common punching machine is the conical roller punching machine. This kind of punching machine has high production efficiency, good product quality, large amount of perforation and expansion, and can wear a variety of steel grades.
After perforation, the round tube blank is successively cross-rolled, continuously rolled or extruded by three rolls. After extrusion, the tube should be removed and sizing. The sizing machine rotates into the steel billet at high speed through the conical drill bit to punch holes to form steel pipes. The inner diameter of the steel pipe is determined by the outer diameter of the drill bit of the sizing machine. After the steel pipe is sizing, it enters the cooling tower and is cooled by water spray. After the steel pipe is cooled, it will be straightened.
| Grade | C(Max) | Mn | Si(Min) | P(Max) | S(Max) |
| A1 | 0.27 | Max 0.93 | 0.10 | 0.035 | 0.035 |
| Grade | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) |
| A1 | ≥415 | ≥255 | ≥30 |
roduct Name | Thick wall seamless steel pipe |
Wall Thickness | 1.5mm-100mm |
Length | 3m-12m |
Outer diameter | 22mm-650mm |
Tolerance | Wall Thickness:±0.05MM Length:±6mm Outer Diameter:±0.3MM |
Shape | Round, Square, Rectangle, Oval |
Material | Q195-Q345, 10# ,20#,45#,195-Q345, Gr.B-Gr.50, S235JR, SS400, SPHC,BS-040A10 ,16mn, 40cr, 42crmo, 27simn, 12cr1mov, 15crmo, Gcr15,25mn2 |
Standard | ASTM, DIN, JIS, BS, GB |
Certificate | ISO, CE, BV |
Delivery time | Delivered within 7-15 days after receipt of deposit |
Package | 1. Packed with 8 bundles tightened with metal belt and plastic wrapped if need |
Application | Widely used in furniture,interior decoration, fluid pipeline, petroleum and natural gas industry, drilling, pipeline, structure |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce hot/cold rolled steel, galvanized steel, galvalume steel, thick wall seamless steel pipe and stainless steel coils,,strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
| 304 stainless steel pipe stainless steel | stainless steel pipe hangers |
| 4in stainless steel exhaust pipe | 1/2 inch stainless steel threaded pipe |
| 6 inch double wall stainless steel chimney pipe | 2.5 stainless steel exhaust pipe kit |
| pipe fittings stainless steel | 3/4 stainless steel pipe price |
| schedule 40 stainless steel pipe dimensions | 304 stainless steel exhaust pipe |
| stainless steel pipe baton rouge | 409 stainless steel exhaust pipe |
| stainless steel pipe bender | 6 inch double wall stainless steel stove pipe |
| stainless steel pipe fittings near me | 6 inch stainless steel stove pipe single wall |
We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.
thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength
We are a world-renowned thick wall seamless steel pipe exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries
