316 Stainless Steel Square Bar description
Stainless steel square bar is a stainless steel bar with four equilateral sides. Stainless steel square bar has excellent forming and welding characteristics and commonly used in industrial applications. Stainless steel square bar has superior corrosion resistance with high tensile strength, thus making it suitable for construction and structural applications. Stainless steel square bar also has good machinability and high durability for jobs in high intensity settings.
email
enquire now
316 is molybdenum-bearing austenitic stainless steel, which increase general corrosion resistance, improves resistance to pitting from chloride ion solutions, and provides increased strength at elevated temperatures. The higher nickel and molybdenum content in this grade allows it to demonstrate better overall corrosion resistant properties than 304, especially with regard to pitting and crevice corrosion in chloride environments.
In addition, Alloy 316/ 316L provides excellent elevated temperature tensile, creep and stress-rupture strengths, as well as outstanding formability and weldability. 316L is the lower carbon version of 316 and is immune from sensitization; therefore, it is very frequently used in heavy gauge welded components.
APPLICATIONS
Uses of stainless steel square bar include industrial, engineering, construction, heat treatment, semiconductors, chemical processing, pharmaceutical equipment, nuclear power and chemical plant, automobiles, aerospace and food processing.
Chemical Composition (%) of 316 Stainless Steel Bar
| C | Mn | Si | P | S | Cr | Mo | Ni | N |
| 0.08 | 2.00 | 0.75 | 0.045 | 0.03 | 16.0-18.0 | 2.00-3.00 | 10.0-14.0 | 0.10 |
Mechanical Properties of 316 Stainless Steel Bar
| 0.2% Offset Yield Strength, ksi | Ultimate Tensile Strength, ksi | Elongation in 2 inches, % | Hardness, Rockwell B |
| 25 min | 70 min | 40 min | 95 max |
Physical Properties of 316 Stainless Steel Bar
| Density lb/inᶟ | 0.285 |
| Density g/cmᶟ | 7.89 |
| Melting Range | 2470-2555°F/1354 – 1402 °C |
| Thermal Conductivity at 212°F (100°C) | 8.0 BTU/hr/ft²/ft/°F |
| Thermal Conductivity at 212°F (100°C) | 10.8 W/m-°K |
| Electrical Resistivity | 30.7 Microhm-in at 68°C |
| Electrical Resistivity | 78 Microhm-cm at 20°C |
Name | Stainless steel bar , stainless steel rod |
Shape | Round bar,Angle bar,Channel bar,Square bar,Flat bar,I/H bar,Hexagonal bar and profiles |
Outer | Peeling Bar: 16~180mm |
Length | 3000mm, 5800mm, 6000mm, 9000m, 12000mm etc. |
Standard | ASTM JIS AISI GB DIN EN |
Surface Finished | BA, 2B,NO.1, NO.4, 4K, HL ,8K |
Application | It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture, |
Certification | ISO 9001 BV SGS |
Technique | Hot Rolled,Cold Rolled,Cold Drawn,Forged |
Edge | Mill Edge /Slit Edge |
Quality | Raw material control + spectrometer inspection + weighing before shipment |
Grade | 200series:201, 202, 304, 304L, 304H, 316, 316L,316Ti,2205, 330, 630, 660, 409L, 321, 310S, 410, 416, 410S, 430, 347H, 2Cr13, 3Cr13 etc |
Grade (EN) | 1.4301, 1.4307, 1.4541, 1.4401, 1.4404 ,1.4571, 1.4438, 1.4539, 1.4547, 1.4529, 1.4562, 1.4410, 1.4878, 1.4845, 1.4828, 1.4876, |
Brand Name | TISCO,ZPSS,Baosteel,POSCO,LISCO,YUSCO,Ansteel, QPSS,JISCO,HXSCO, |
Delivery time | Fast delievery in 7 days,up to order quantity |
Port of Loading | Shanghai |
Trade Terms | CIF CFR FOB EX-WORK |
Export Packing | Industry standard packaging or according to client's requirement |
Supply Ability | 5000 Ton/Tons per Month |
Payment Terms | T/T L/C and Western Union etc. |
Container Dimension | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM |
