0.8-1.3mm Prepainted Gi Steel Coil|Gi Cold Rolled Ring Coil

Galvanized coil hot dip galvanized advantage :

Continuous hot-dip galvanizing is widely used in the production of hot-dip galvanized steel coil. The process of continuous hot dip galvanizing method can be simply described as: original plate & GT; Pre-plating treatment (cleaning and annealing) & GT; Hot dip galvanizing & GT; Post-plating treatment (such as zinc flower treatment, alloy treatment and chemical treatment, etc.) & GT; The finished product.

1, low processing cost: the cost of hot dip galvanized rust is lower than the cost of other paint coating;

2, durable: in the suburban environment, the standard hot-dip galvanized rust prevention thickness, can be maintained for more than 50 years without repair; In urban and offshore areas, the standard hot-dip galvanized coating can be maintained for 20 years without repair.

3, good reliability: galvanized layer and steel is metallurgical combination, become a part of the steel surface, so the durability of the coating is more reliable;

4, the toughness of the coating is strong: galvanized layer forms a special metallurgical structure, this structure can withstand mechanical damage in transport and use;

5, comprehensive protection: each part of the plated parts can be plated with zinc, even in the depression, sharp corners and hidden places can be fully protected;

6, save time and effort: galvanizing process is faster than other coating construction method, and can avoid the installation in the site after the time required to brush;

Mechanical Properties of Gi Cold Rolled Ring Coil

Surface Structure

Surface Structure	Zero Spangle	Big Spangle
Weight of Zinc Coating	Zinc > 20g/sqm	Zinc > 30g/sqm

Mechanical Properties

Grade	Yield Strength	Tensile Strength	Mechanical properties elongation after breaking	R90	N90
	MPa	MPa	A 80mm %	not less than	not less than
	MPa	MPa	not less than	not less than	not less than
DX51D+Z	240-380	270-500	24	-	-
DX52D+Z	140-300	270-420	26	-	-
DX53D+Z	140-260	270-380	30	-	-
DX54D+Z	120-220	260-350	36	1.6	0.18

Product Specification of Gi Cold Rolled Ring Coil

Standard	AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Material	SGCC/ CGCC/ DX51D+Z
Thickness(mm)	Hot Rolled Thickness:0.12 ~ 3.00 mm Cold Rolled Thickness:1.20 ~ 4.60 mm As Your Request
Width(mm)	600mm-2200mm, As Your Request Regular width 1000mm, 1250mm, 1500mm
Tolerance	Thickness: ±0.01 mm Width: ±2 mm
Coil ID	508-610mm or as per your request
Coil Weight	3~5 Tons or as per your request
Zinc Coating	30g - 275g / m2
Spangle	Big spangle,Regular spangle,Mini spangle,Zero spangle
Surface Treatment	Coated,Galvanized,Clean, Blasting and Painting according to customer requirement

call us now！ +86-18365977887 Or write to us at Echo@kuaimasteel.com

Galvanized steel coil Production Line

Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce hot/cold rolled steel, galvanized steel coil, galvalume steel, prepainted steel and stainless steel coils,,strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.

Hot Products

china hot dipped galvanized steel coil	hot dipped galvanized steel coils
coil coated galvanized steel	prepainted galvanized steel coil manufacturers
cold rolled galvanized steel coil	prepainted galvanized steel coil suppliers
color coated galvanized steel coil	prime galvanized steel coil
full hard galvanized steel coil g550	prime hot dipped galvanized steel coils
galvanized coil steel mud mats	steel coil galvanized
galvanized steel coil china	wholesale gi sheet galvanized steel coil
galvanized steel coil manufacturers	best galvanized steel coil

Galvanized steel coil Quality Inspection

We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.

thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength

Galvanized steel coil Application Industry

Machinery manufacturing industry
Oil & Gas Industries
Construction industry
Shipbuilding industry
Chemical industry
Power Generation

Galvanized steel coil outlet

We are a world-renowned PPGI/prepainted galvanized steel coil exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries
