A large number of galvanized thin coils are used in automobile manufacturing, refrigerated containers, construction, ventilation and heating facilities, and furniture manufacturing. Zinc plating has become an important method of steel corrosion protection, not only because zinc can form a dense protective layer on the surface of steel, but also because zinc has a cathodic protection effect. When the galvanized layer is damaged, it can still prevent iron mothers through cathodic protection. Material corrosion.
The specification of galvanized coil is generally 0.4~2.0 in thickness of common galvanized sheet. Generally smaller than 0.4mm, large state-owned steel mills do not produce, but generally small steel mills of private enterprises. The conventional specifications are 0.35, 0.30, 0.28, 0.25, and generally the thinnest is 0.15. If straightening is difficult for more than 2.0mm, straightening is difficult, so more than 2.0 As the thickness increases, the price also rises.
Surface Structure
Surface Structure | Zero Spangle | Big Spangle |
Weight of Zinc Coating | Zinc > 20g/sqm | Zinc > 30g/sqm |
Mechanical Properties
Grade | Yield Strength | Tensile Strength | Mechanical properties elongation after breaking | R90 | N90 |
MPa | MPa | A 80mm % | not less than | not less than | |
not less than | |||||
DX51D+Z | 240-380 | 270-500 | 24 | - | - |
DX52D+Z | 140-300 | 270-420 | 26 | - | - |
DX53D+Z | 140-260 | 270-380 | 30 | - | - |
DX54D+Z | 120-220 | 260-350 | 36 | 1.6 | 0.18 |
Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
Material | SGCC/ CGCC/ DX51D+Z |
Hot Rolled Thickness:0.12 ~ 3.00 mm Cold Rolled Thickness:1.20 ~ 4.60 mm As Your Request | |
Width(mm) | 600mm-2200mm, As Your Request Regular width 1000mm, 1250mm, 1500mm |
Tolerance | Thickness: ±0.01 mm Width: ±2 mm |
Coil ID | 508-610mm or as per your request |
Coil Weight | 3~5 Tons or as per your request |
Zinc Coating | 30g - 275g / m2 |
Spangle | Big spangle,Regular spangle,Mini spangle,Zero spangle |
Surface Treatment | Coated,Galvanized,Clean, Blasting and Painting according to customer requirement |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce hot/cold rolled steel, galvanized steel coil, galvalume steel, prepainted steel and stainless steel coils,,strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
