Gi Coil Zinc 60g|Zero Spangle Cold Rolled Gi Coil dealer
Spangle on galvanized steel is formed during solidification process of the zinc layer, including normal spangle, minimized and zero spangles.
email
enquire now
The electrochemical potential of the hot-dip galvanized layer of the galvanized coil is more negative than that of the steel material, and the coating has excellent electrochemical protection performance. The coating layer is thick and dense, the coating layer and the steel substrate have strong bonding force, and the durability is good. The service life of the hot-dip galvanized steel with a galvanizing amount of 600g/m2 can reach more than 30 years. The hot-dip galvanized steel layer does not require maintenance during use. The hot-dip galvanizing process is simple and has strong adaptability to the shape and size of the steel. In addition to the strip steel, the hot-dip galvanizing process is also widely used in steel pipes, steel wires and structural parts, and has high productivity. Compared with other protective coatings economically, the galvanized layer has a strong competitiveness, especially for long-term used parts, the cost of the hot-dip galvanized layer is much lower than that of the paint coating.
Surface Structure
| Surface Structure | Zero Spangle | Big Spangle |
| Weight of Zinc Coating | Zinc > 20g/sqm | Zinc > 30g/sqm |
Mechanical Properties
| Grade | Yield Strength | Tensile Strength | Mechanical properties elongation after breaking | R90 | N90 |
| MPa | MPa | A 80mm % | not less than | not less than | |
| not less than | |||||
| DX51D+Z | 240-380 | 270-500 | 24 | - | - |
| DX52D+Z | 140-300 | 270-420 | 26 | - | - |
| DX53D+Z | 140-260 | 270-380 | 30 | - | - |
| DX54D+Z | 120-220 | 260-350 | 36 | 1.6 | 0.18 |
Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
Material | SGCC/ CGCC/ DX51D+Z |
Hot Rolled Thickness:0.12 ~ 3.00 mm Cold Rolled Thickness:1.20 ~ 4.60 mm As Your Request | |
Width(mm) | 600mm-2200mm, As Your Request Regular width 1000mm, 1250mm, 1500mm |
Tolerance | Thickness: ±0.01 mm Width: ±2 mm |
Coil ID | 508-610mm or as per your request |
Coil Weight | 3~5 Tons or as per your request |
Zinc Coating | 30g - 275g / m2 |
Spangle | Big spangle,Regular spangle,Mini spangle,Zero spangle |
Surface Treatment | Coated,Galvanized,Clean, Blasting and Painting according to customer requirement |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce hot/cold rolled steel, galvanized steel coil, galvalume steel, prepainted steel and stainless steel coils,,strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
| galvanized steel coil manufacturers | galvanized steel sheet coil quotes |
| galvanized steel coils for sale | galvanized steel in coils |
| galvanized steel sheet coil | galvanized steel coil supplier |
| galvanized steel sheet in coil | galvanized steel sheet in coils |
| hot dipped galvanized steel coils | hot dip galvanized steel coil |
| prepainted galvanized steel coil manufacturers | hot dipped galvanized steel coil |
| galvanized steel coil sheet quotes | galvanized steel sheet coil quotes |
| galvanized steel coil manufacturer | galvanized steel in coils |
We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.
thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength
We are a world-renowned PPGI/prepainted galvanized steel coil exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries
