4140 alloy steel plate
4140 steel is a chromium, molybdenum, manganese low alloy steel plate that is known for its toughness, high fatigue strength, and high torsional strength.
email
enquire now
4140 steel plate has high fatigue strength, excellent toughness, and good corrosion resistance. One disadvantage is the extra care that must be taken when welding it.
This material is often used for shafts, crankshafts, gears, collars, and machinery parts because of its toughness, abrasion and impact resistance, and high fatigue strength.
It is hardened by heating to 1550°F or 845°C followed by quenching in oil.
| CR | MN | C | SI | MO | S | P | FE |
|---|---|---|---|---|---|---|---|
| 0.8 - 1.10 | 0.75 - 1.0 | 0.380 - 0.430 | 0.15 - 0.30 | 0.15 - 0.25 | 0.040 | 0.035 | Balance |
| PROPERTIES | METRIC | IMPERIAL |
|---|---|---|
| Tensile Strength | 655 MPa | 95,000 PSI |
| Yield Strength | 415 MPa | 60,200 PSI |
| Bulk Modulus | 140 GPa | 20,300 KSI |
| Shear Modulus | 80 GPa | 11,600 KSI |
| Elastic Modulus | 190 - 210 GPa | 26,557 - 30,458 KSI |
| Poisson's Ratio | 0.27 - 0.30 | 0.37 - 0.30 |
| Elongation at Break (50mm) | 25.7% | 25.7% |
| Brinell Hardness | 197 | 197 |
| Machinability (set to AISI 1212 as 100 Machinable) | 65 | 65 |
Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce Alloy steel plate，hot/cold rolled steel, galvalume steel, galvanized steel, prepainted steel and stainless steel coils, strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.
We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.
thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength
