304 stainless steel pipe

Product Desceription of 304 stainless steel pipe

The stainless steel 304 pipe is made up of austenitic stainless steel that has 18% chromium and 8% nickel in its alloy. These metallic pipes have ASTM specifications and are in listed the range as A312 and A358. The range of the dimensions is also in accordance with ASME, ASTM, and API standards. Clients can get these SS 304 pipes in welded and electric fusion welded forms. The best used for these pipes is for high temperature and pressure applications- it is commonly found in various services that include commercial, industrial, domestic and general corrosive purposes.
The schedule 40 stainless steel 304 pipe is the most commonly used one as they are very cost-effective. The material is fairly strong and offers general resistance to corrosion. It comes with a low carbon level which makes it ideal for welding, along with reducing the localized corrosion.
The Schedule 10 304 stainless steel pipe has similar standards, but they are used for low pressure capacities. They are also less resistant to corrosion when compared to the SCH 40 SS 304 pipes.

Chemical and Mechanical Properties of 304 stainless steel pipe

Chemical Material Composition of SS 304 seamless pipes
Grade		Mn	C	P	Si	Cr	S	Ni	Mo	N
Stainless Steel 304 Seamless Pipe	minimum	–	–	–	–	18	–	8	–	–
Stainless Steel 304 Seamless Pipe	maximum	2	0.08	0.045	0.75	20	0.03	10.5	–	0.1

Yield Strength of asme sa312 grade 304 pipes
Grade	Strength of Yield 0.2% Proof (MPa) minimum	Elongation (% in 50mm) minimum	Strength of Tensile (MPa) minimum	Pipes Hardness
				Brinell (HB) maximum	Rockwell B (HR B) maximum
Stainless Steel 304 Seamless Pipe	205	40	515	201	92

Product Specification of stainless steel Pipe

Stainless Steel 304 Pipe ASTM Specification	ASTM A312/ SA 312
International Standards	ASME, GB, DTD, DIN, JIS, EN, AMS, TOCT, SAE, AISI, NF, DS, ASTM
Stainless Steel 304 Seamless Pipe Size	OD: 4mm- 219mm，Wall Thickness: 0.5mm - 20mm
304 Stainless Steel Welded Pipe Size	OD: 5.0mm - 1219.2 mm
304 Grade Stainless Steel EFW Pipe Size	OD: 5.0mm - 1219.2 mm
304 Food Grade Stainless Steel Pipe Wall Thickness	SCH 5, SCH 10, SCH 40, SCH 80, SCH 80S, SCH 160 SCH XS, SCH XXS
Manufacturing methods of Austenitic Stainless Steel 304 Pipe	EFW, Redrawn, CDW, Fabricated, Welded, LSAW, Seam-Welded, ERW, Seamless
304 SS Pipe Origin	China, Korean, Japanese, European, Indian
Stainless Steel UNS S30400 Pipe Ends	TOE/POE, BSE, PBE, Beveled(BE), TOE/BOE, TBE, BBE, POE/BOE, BLE
Shape	Square, Rectangular, Hex, Round
SS 1.4301 Pipe Length	Single-Random or Double-Random
Delivery Condition of 1.4301 Stainless Steel Pipe	Hot-Finished, Annealed, Bright-Annealed, Pickled, Cold-Drawn, Polished
DIN 1.4301 Pipe Packing	Wooden Boxes，Steel Strips Bundled，PE Fabric Bundles，Plastic Bags，Standard seaworthy packing for export or custom as required
AISI 304 Pipe Value Added Services	Groove, Polished, Cut to size, and thread
Stainless Steel 304 Pipe surface finish	No. 2B - Mill finish/ Matte finish，No.8 - Mirror finish/ Highly reflective finish，No. 4 - Brushed finish，2D, 2B, 8K, SATIN, No.4, No.8, 1D, BA, mirror, hairline, No.1, brush
AISI 304 Pipe Dimensional Standard	ANSI/ ASME B36.10, B36.19, B2.1
Marking on SUS 304 Pipe	ASTM / ASME Specification，Material Grade，Nominal Size (NPS)，Wall Thickness/ Schedule，Manufacturing Method (Seamless, ERW or Welded)，Heat NumberManufacturer’s id/ Company Logo - as required Sample: 12" NB SCH 40 Stainless Steel 304 Pipe HEAT NO. XYZ

Benefits of using 304 Stainless Steel Pipe

Low carbon content eliminates carbon precipitation in the welding process
Can be used in severe corrosive environments
Weld annealing only required in high stress applications

call us now！ +86-18365977887 Or write to us at Echo@kuaimasteel.com

304 Stainless Steel Pipe Production Line

Shandong Kuaima Steel Co., Ltd. has advanced special smelting, investment casting, pipe making and other production equipment. The company has 15 advanced production lines, which can independently produce hot/cold rolled steel, galvanized steel, galvanized steel, prepainted steel and stainless steel coils, 304 Stainless Steel Pipe,strips, plates, plates, pipes, bars and other products. The standing inventory is more than 450,000 tons to meet the customer's demand for delivery time.

Hot Products

stainless steel pipe for water	stainless steel pipe suppliers near me
threaded stainless steel pipe	stainless steel pipes near me
1 1/4 stainless steel pipe	stainless steel sch 10 pipe
1.5 inch stainless steel pipe	threading stainless steel pipe
1/2 stainless steel pipe	12 stainless steel pipe
2 3/4 stainless steel exhaust pipe	310 stainless steel pipe
4in stainless steel pipe	316l stainless steel pipe
how to cut stainless steel pipe	8 inch stainless steel pipe

304 stainless steel pipe Quality Inspection

We have professional testing equipment. We have our own testing center laboratory to guarantee the quality of our products.

thickness
width
coating quality
chromatic aberration
paint
thickness
hardness
luster
tensile strength
Yield Strength

APPLICATION INDUSTRY

Machinery manufacturing industry
Oil & Gas Industries
Construction industry
Shipbuilding industry
Chemical industry
Power Generation

countries exported

We are a world-renowned 304 Stainless Steel Pipe exporter, Qatar, Ireland, Portugal,Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Ro-Fanaticism, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany,Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece,Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus,Finland, Gabon, Iran, Canada, Argentina, Lebanon. other countries.
